Sylvania QTP1x32T8/UNV DIM-TC (50705) T8 Dimming Fluorescent Ballast

Special Price $73.02 Regular Price $102.22

SKU

BD5-50705

Sylvania Fluorescent Dimming Ballast - Lamps: (1) F32T8, (1) F25T8, (1) F17T8 -Input:120-277V -Starting: Programmed Rapid Start

DISCONTINUED by Sylvania. See the new high efficiency version as the replacement - Sylvania 50735

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Sylvania Electronic Fluorescent 1 Lamp T8 Step Dimming Ballast (50705)

SYLVANIA QUICKTRONIC POWERSENSE ballasts operate linear fluorescent T8 lamps over a wide (100 - 5%) dimming range and provide true versatility in controls selection.

POWERSENSE compatibility with low voltage and power line dimmers

High Efficiency

Lamp Detection Technology

Universal voltage (120-277)

100 - 5% Dimming Range

PROStart programmed start

Anti-flash circuitry - turns on in dimmed mode

Lightweight and low profile

Operates at >42kHz

QUICK 60+ ballast and lamp warranty

More Information

More Information
Order Code	QTP1x32T8/UNV DIM-TC (50705)
Input Volts	120/277V
Brand	Sylvania
Mfg #	50705
# of Lamps	1 Lamp
Product Data Sheet	Quicktronic Powersense
Certifications	Class P, CSA, NEMA Premium, Outdoor Type 1, Sound Rated: A, UL
Equivalents	NA
Start Method	Programmed Start
Starting Temperature	32°F, 0°C
Lamps	(1) F32T8, (1) F25T8, (1) F17T8
Dimensions	9.50 x 1.68" x 1.18"
Case Size	10
Warranty	5 Year Sylvania Limited Warranty
UPC	46135507052
