KTLD-45-UV-PS850-54-VDIM-LM1 Keystone Power Selectable 45w Constant Current LED Driver
Special Price
$26.48
Regular Price
$33.10
SKU
17039
Power Selectable Switchable Constant Current Dimmable LED Driver: 45 Total Watts, 700, 750, 800 or 850mA Output Current, 54 VDC Output Voltage, 120-277 VAC Input Voltage, Class 2, 0-10v Dimming Control, 10%-100% Dimming Range
KTLD-45-UV-PS850-54-VDIM-LM1 Keystone Power Selectable 45w Constant Current LED Driver
- Over voltage protection
- Over current protection
- Short circuit protection
- 5-year warranty
| Life (hrs) | 50,000 |
|---|---|
| Order Code | FOO-58 |
| Input Volts | 120-277 VAC |
| Output Current | 700, 750, 800 or 850mA |
| Max Output Voltage | 54 |
| Watts | 45 |
| Brand | Keystone |
| LED Type | Constant Current |
| Certifications | Class P, cULus, FCC, RoHS, EN61000-3-2 Harmonic Current Emissions Class C, FCC Part 15 Class B, CE EN61347-1, CE EN61347-2-13 |
| Class | Class 2 |
| Dimmable | Yes |
| Dimming Type | 0-10v |
| Mfg # | KTLD-45-UV-PS850-54-VDIM-LM1 |
| Dimensions | 9.49 in. x 1.23 in. x 1.15 in. |
| Product Data Sheet | |
| Warranty | Manufacturer's 10 year |
| UPC | 843654128443 |
