Advance Mark 10 REZ-154 T5 Dimming Ballast

Availability: In stock

Retail Price: $229.90

Special Price: $116.55

Quick Overview

Advance Mark 10 REZ-154 Dimming Fluorescent Ballast for (1) F54T5/HO, (1) F54T5/HO/ES(49W), (1) FC12T5/HO, (1) FT55W/2G11. Input for 120v.
Advance Mark 10 REZ-154 T5 Dimming BallastAdvance Mark 10 REZ-154 T5 Dimming Ballast
Move your mouse over image or click to enlarge
Advance Mark 10 REZ-154 T5 Dimming Ballast Advance Mark 10 REZ-154 T5 Dimming Ballast Advance Mark 10 REZ-154 T5 Dimming Ballast Advance Mark 10 REZ-154 T5 Dimming Ballast

Details

REZ-154

Advance Mark 10 REZ-154 Dimming Ballast

Mark 10 Powerline electronic controllable ballasts for linear T8 lamps combine the long life and energy efficiency of fluorescent technology with the controllability and full-rangedimming of incandescent systems. And they’re easy to install because they require no additional wiring.

  • Programmed Start
  • Ballast operates from 60 Hz input source of 120V as applicable with sustained variations of +/- 10%
  • Lamp Current Crest Factor of 1.7
  • Class A Sound Rating
  • Additional Information

    Order Code REZ15435M
    Input Volts 120V
    Brand Advance Mark 10
    Family No
    Mfg # REZ15435M
    # of Lamps 1 Lamp
    Product Data Sheet
    Certifications Class P, CSA, FCC Part 18 (Class A), Outdoor Type 1, Sound Rated: A, UL
    Equivalents Lutron ECO-T554-120-1, Lutron FDB-T554-120-1
    Start Method Programmed Start
    Starting Temperature 50ºF, 10ºC
    Lamps (1) F54T5/HO, (1) F54T5/HO/ES(49W), (1) FC12T5/HO, (1) FT55W/2G11
    Dimensions 16.7" x 1.18" x 1"
    Case Size ea
    Warranty 3 Year Advance Warranty
